测试内容

亮度L、色度xy、u'v’、色温Tc、主波长、色差、光谱

分辨率

12M              31M              151M              11.7M               62M

靶面尺寸

14.2x10.4      22.3X16.7      46.3X34.8       17.3X13           36X24

制冷

无                 无             TEC制冷        TEC制冷        TEC制冷

最小亮度

0.05              0.05              0.05             0.005            0.005

最大亮度

>100,000cd/m²

精度

亮度±3%，色度（Cx Cy）±0.003cd/m²（基于内置光谱仪）

重复性

±0.05%（@1000nit）±0.0001（@1000nit）

镜头焦距

24/28/35/50    24/28/35/50      95/105/4X     24/28/35/50       35/50/85

通讯接口

GigE             10GigE           10GigE           USB3.0          USB3.0

测试时间

1.5s                2s                 3s                1.8s                 4s

带宽                                                5nm

测试直径                           Φ12mm(500mm测试距离)

亮度范围                                 0.02 to 20000 cd/m²

亮度精度                                           ±3%

色度精度                                         ±0.002

测试时间                                  100 µsec to 3 sec

测试项目                                   光谱、亮度、色度

位深                                              16bit
